Application:
1. Isolating
2. Flow control (Maximum flow velocity 3 m/s)
• Easy installation and maintenance, low pressure drop.
• Suitable installation between flanges that are drilled in accordance with EN1092-2 or ASME B 16.5 without need of sealing washer for installation.
• Body and disc made of ductile iron EN1563 (GJS 400)
• Seat made of wear resistant EPDM rubber DIN53538-5
• Can be installed to electric actuator according to ISO5211. (Upon request)
• Possibility of installation in any desired position.
